High speed automation solutions for electronics test, measurement, and manufacturing.

Buy online now

KEY COMPONENTS AND SOLUTIONS FOR ELECTRONICS MANUFACTURING, TEST AND MEASUREMENT

Motion Plus has a wide array of products that were developed specifically for electronics manufacturing applications including dispensing, via drilling, flat panel processing, laser-direct imaging, wafer dicing, and semiconductor processes. Whatever motion control your electronics manufacturing application requires; Motion Plus can be the partner that ensures your project is a success.

HOW CAN WE HELP WITH YOUR ELECTRONICS MANUFACTURING NEEDS?

With Precision Controls:

  • Position Synchronized Output (PSO) allows for triggering a process event on a calibrated encoder position. This is deal for LCD manufacturing, laser direct imaging, via drilling, wafer dicing, high-precision position-based data acquisition
  • Infinite Field of View (for Galvo Applications) allows the AGV series to process large areas in seconds, limited only by the maximum speeds of the servo-stages
  • Enhanced Throughput Module significantly improves move-and-settle time and contouring performance, increasing throughput of new and existing machines
  • Enhanced Tracking Control improves move-and-settle times in point-to-point positioning and reduces tracking errors during contoured motion
  • CADFusion CAD to G-Code Software allows for easy importing of vector-based drawing files and produces motion programs for our Aerotech controllers

With Motors & Precision Positioning Stages:

  • Multi-axis assemblies from 2 to 6+ degrees of freedom are tailored for printing/dispensing along complex contours
  • Large travel air-bearing XY optimized for flatpanel processing
  • The QNP and QNPHD high-precision piezo stages are optimized for dynamic motion and best-in-class geometric performance
  • Linear motors enable high-precision motion with high dynamics: 2 m/s velocities and 2g accelerations

SUCCESSES

APPLICATION AREAS
MOTION CONTROL & AUTOMATION FOR:
  • Solder Ball Placement
  • Precision Assembly
  • Display Processing
  • Laser Lift-Off
  • Mass Transfer Printing
  • Flexible Electronics Printing
  • Wafer Dicing
  • Stencil Cutting
  • Assembly
  • Flat-Panel Processing and Inspection
  • Dispensing/Printed Electronics
KEY PRODUCTS
KEY APPLICATION NEEDS
  • High speed throughput
  • High precision flatness
  • High precision straightness
  • Minimal accuracy and repeatability errors
